| Quantity: | |
|---|---|
F411 35A 3-6S
Product features:
1. The PCB uses high-end 6-layer 2oZ thickened copper skin, which has stronger over-current capability and good heat dissipation.
2. MOS adopts imported 30V high current resistance MOS, which has long life and strong load capacity.
3. Use industrial grade LDO, resistant to high temperatures.
4. Use high-quality Japanese Murata capacitors with strong filtering performance
| Product specifications | |
Size: | 39.5.* 31.5mm (20*20mm mounting hole) |
Packing size: | 63*63*32mm |
Product net weight: | 10g |
Packing weight: | 27g |
| Flight control parameters: | |
| CPU: | STM32F411CEU6 |
| IMU: | MPU6000 |
| OSD: | AT7456E |
| Black box: | 16M |
| Barometer: | BMP280 |
| BEC: | 5V/3A; 10V/2.5A |
| LED: | supports WS2812 and other programmable |
| Sensor: | Built-in current sensor |
| Firmware version: | betaflight_4.1.1_MATEKF411 |
| Receiver: | Frsky/ Futaba/ Flysky/ TBS Crossfire/ DSMX:DSM2 receiver |
ESC parameters: | |
Continuous current: | 35A |
| Firmware version: | BLHELI_S (C-H-30) |
| Peak current: | 40A |
| Input voltage: | 3S-6S Lipo |
| Firmware | support: BLHELI_S |
| Protocol support: | PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600 |
