| Quantity: | |
|---|---|
35A F722
| Product specifications | ||||
Packing size: | 64*64*35mm | Flight control parameters | ||
Product net weight: | 13.2g | Flight control size: | 29x29mm | |
Packing weight: | 56g | Flight control net weight: | 6g | |
| ESC parameters： | Installation hole distance: | 20*20mm φ4mm | ||
| Adjustable size: | 31mm*30mm | Processor: | STM32F722RET6 | |
ESC net weight: | 6g | Gyroscope: | ICM42688 dual gyroscope | |
| Fixed hole spacing: | 20mm*20mm Φ4mm | B E C: | 5V/2A; 10V/2A | |
Continuous current: | 35A | Memory: | 16MB | |
Maximum current: | 40A (sustainable for 10S) | Input voltage: | 2S—6S | |
| Input voltage: | 2S-6S | Firmware: | HAKRCF722V2 | |
Current ratio: | 300 | Uart serial port: | 6 | |
| Parameter adjustment software: | BLHeliSuite16.7.14.9.0.3 | Support external programmable LED | ||
| Drive signal support: | PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600 | Comes with 6P air terminal | ||
Parts List
M2 orange shock absorbing balls x8,
8p line x1,
DJI6P cable x1,
Capacitor (35v270uf) x1,
XT60 power head x1,
Red and blue power cord x1,
(M2x25mm screw)x4,
Black nuts x4,
DJI O3 Air Unit three-in-one cable x1,
Instruction x1
